Flat Die Pellet Mill

  • ZLSP120 D-Type Flat Die Pellet Mill: Capacity: 75-100KG/H
    Power:3KW Net Weight: 93KG Outside dimension: 770*420*750MM
  • ZLSP200A D-Type Flat Die Pellet Mill: Capacity: 250-350KG/H
    Power:15HP Net Weight:310KG Outside dimension:1340*500*660MM
  • ZLSP230A D-Type Flat Die Pellet Mill: Capacity: 250-350KG/H
    Power:22HP Net Weight:350KG Outside dimension:1400*660*1030MM
  • ZLSP360A D-Type Flat Die Pellet Mill: Capacity: 800-1000KG/H
    Power:22KW Net Weight:690KG Outside dimension:1320*600*1050MM
  • ZLSP400A D-Type Flat Die Pellet Mill: Capacity: 800-1000KG/H
    Power:30KW Net Weight:690KG Outside dimension:1320*600*1050MM

For Wood Pellet Fuel
As we know, the original design of flat die pellet mills are used for processing feedstuff. But through our client's feedback and diligent research, flat die pellet mill is applied in processing wood sawdust, straw, different kinds of stalks, grass, etc. When process wood materials, whether it need add binder into it depends on the fiber content and resin content of raw material. Because the material need have certain content of resin content to bind them together. If the raw material have no enough resin content, little binder such as oil cake or fecula residue etc. During our several times tests, if add little binder into the material, the appearance of final pellets will become bright wood pellet fuel.

For Feedstuff
As one kind of renewble energy machinery which can process wood sawdust, wood lump and other agro-waste materials, our ZLSP D-Type series flat die pellet mill is very popular for farmers who feed large quantity of animals in China. It features cheap price, low consumption, high capacity etc. The series wood pellet machine is a desirable choice for small feeding plant which can save time and cost for them.

During the process of pelletizing, the temperature of wood pellet machine can reach about 70-80 centigrade, which can make fecula into paste. The granule inside wood pelletizer has already been fully cooked. Because lignin in plants is indigestible by animal enzymes, the cooking process can decompose the lignin. So the pellets after cooked will be not easy to go moldy and degenerative, thus the pellets can be stored for a longger time. At the same time, it can improve the dainty and assimilation function of animal feedstuff. To pelletizing the animal feedstuff by flat die pellet mills can shorten the period of feeding, which make feeding more efficiently and lower users’ productive cost.

Raw Material

The best moisture content for wood pelletizer is between 13%-15%.
The best size of raw material is granule udner diameter 4mm.
